FS-AVC400-6S

FS-AVC400-6S Compact Pneumatic Vacuum Sheet Lifter

The FS-AVC400-6S is especially suited to sheets with uneven surfaces and to long periods of continuous work
Fast gripping, high vacuum level and long service life,
The FS-AVC400-6S also lifts and moves flat, smooth metal or non-metal sheets
Fully pneumatic, requiring a compressed air supply of 7kg/cm2.
The FS-AVC400-6S is ideal for loading laser cutting machines in tight spaces with continuous, high-frequency operation
Designed to pair with FullSharp pneumatic jib cranes.
Anti-drop protection holds the load even if the air supply is lost.
Grip / release / release-confirm controls, or simultaneous two-button operation, prevent accidental release.

Specifications - FS-AVC400-6S

Model	Safe working load	Dimensions (mm)	Pad diameter (mm)	Number of pads	Power source	Control	Function
FS-AVC400-6S	400kg	3000 × 1000 × 500	Φ200	6 pads	Compressed air (0.7 ~ 0.8 Mpa)	Manual	Air blow-off sheet release

Applications

**Loading steel sheets onto a CNC cutter**Pneumatic jib crane, 150 kg vacuum lifter

**Steel sheets from rack to cutting machine**500 kg rail jib crane

**Lifting metal sheets from a sheet rack**Pneumatic jib crane with vacuum lifter

**Lifting steel plates onto a work table**Pneumatic jib crane with vacuum lifter

**Feeding metal sheets to a laser cutter**Pneumatic jib crane with vacuum lifter

Completed Projects (click to view details)

Car door lifting solution with a vacuum tool, double-girder 5T ceiling rail and ENDO air hoist

A car door lifting solution for an automotive parts plant: vacuum tool, double-girder 5T ceiling rail and ENDO air hoist. One operator lifts, moves and racks each door.

Wood panel loading onto a cutting machine with a jib crane and a 360 degree rotating vacuum lifter

A panel cutting shop needed to load 100–400 kg wood and cement boards onto the cutting table. FullSharp installed a jib crane with an electric hoist and a vacuum lifter that rotates and tilts 360 degrees, so one operator can do the job.

5T rail 200 kg: a lifting solution for steel doors

FullSharp installed a 5T rail system rated 200 kg with a remote-controlled COMEUP electric hoist and a pneumatic vacuum tool that tilts between horizontal and vertical, so a steel door workshop can lift, move and stand up door panels without manual carrying.

Lifting metal sheets onto a CNC cutter with a battery-powered vacuum lifter

FullSharp installed a 500 kg jib crane with an electric hoist and a multi-pad battery-powered vacuum lifter, so one operator can lift metal sheets in the workshop and load them onto a CNC cutting machine quickly and safely, without scratching the sheets.

Pneumatic Jib Crane with 150 kg Pneumatic Vacuum Lifter for Loading Steel Sheets onto a CNC Cutter

A steel sheet loading solution for CNC cutters: pneumatic jib crane with a 150 kg pneumatic vacuum lifter – compact, fast, no power cable and no battery charging.

500kg Rail Jib Crane with Pneumatic Vacuum Lifter from Steel Sheet Rack to Cutter

A 500kg rail jib crane with a COMEUP electric hoist and a 400kg pneumatic vacuum lifter moves 3000 x 1500 mm steel sheets from a sheet rack to a laser cutter.

500kg Rail Jib Crane with 500kg Electric Vacuum Lifter for Steel Sheets

A 500kg rail jib crane with a COMEUP electric hoist and a 500kg electric (vacuum pump) lifter loads 3000 x 1500 mm steel sheets onto a CNC cutting machine quickly and safely.

Manual Cylinder Vacuum Lifting Pad, 400kg

Mechanical vacuum lifting pad that creates suction using a cylinder mechanism, holding flat, airtight objects up to 400 kg. No electricity or compressed air needed — flip the lever to grip, flip it back to release.

500 kg Jib Crane with Vacuum Lifting Pad for Steel Sheets on Laser CNC Machines

A 500 kg jib crane fitted with a vacuum lifting pad, built to lift steel sheets onto laser CNC cutting machine tables. No bent edges, no scratches, and a single operator handles the whole job. Includes an installation photo album at the cutting shop.

500 kg Jib Crane with Battery-Powered Vacuum Lifter

A 500 kg jib crane fitted with a battery-powered vacuum lifter, lifting flat sheets with no air hose required. The installation photo album documents the full column setup and load testing process.

Pneumatic Vacuum Lifting Pad for 8 m Long Steel Sheets

A multi-point pneumatic vacuum lifting pad built to lift 8 m long steel sheets without any sling work. The installation photo album documents load testing and actual sheet handling on site.

500 kg Rail with KITO Hoist and Vacuum Lifter for 90° Wood Panel Tilting

A 500 kg rail system with a KITO hoist and a vacuum lifting pad that grips wood panels and tilts them 90 degrees into the machine. Photo album of the actual installation at the customer's wood workshop.
