FS-QXQ

Safe load250 kg
Suction cups4 × Dia. 250
Size850×570 mm, extended 1800×570 mm
PowerCompressed air 0.6–0.8 MPa
FunctionVertical 0–90° pneumatic rotation
ControlManual

FS-QXQ pneumatic vacuum lifter: vertical 0–90° glass rotation, 250 kg

FS-QXQ pneumatic rotation series. Load: 250 kg. Power system: compressed air, 0.6–0.8 MPa.

The lifter is made for insulating glass sealing machines, vertical edging machines, vertical drilling machines, vertical laminating machines and similar equipment. Air cylinders lift and lower the glass and rotate it vertically from 0 to 90°. The structure is compact and easy to operate. At a fixed station it works with a pillar jib crane, a wall-mounted jib crane or an overhead rail.

FS-QXQ pneumatic vertical glass rotation vacuum lifter

Specifications

Model	Safe load	Size (mm)	Suction cup diameter (mm)	Number of suction cups	Power system	Control mode	Function
FS-QXQ250-4S	250 kg	850×570; extended: 1800×570	Φ250	4	Compressed air (0.6–0.8 MPa)	Manual	0–90° pneumatic rotation

Main components

High quality cylinder

High quality cylinder from an internationally known brand / Stable power output / Durable

Vacuum suction cup

Suction cup rubber Dia. 250 mm, nitrile rubber / Three-ring multi-cavity seal / Good pressure holding, safer

Equipment frame

Professionally custom made by the factory / National standard structural steel profiles / Welded, machined, shaped and finished with baked paint, durable

Other spare parts

Power switches, vacuum generator and other parts from internationally known brands / UL and other international certifications / Low failure rate, durable

Application scenes

**Operating the handle while rotating glass vertically**

**Loading glass onto a vertical insulating glass line**

Product advantages

Cylinder lifting, vertical 0–90° rotation

FS-QXQ lifters use cylinder lifting and vertical 0–90° pneumatic rotation. The unit is compact and gives a high degree of flexibility and precision when handling glass, while staying convenient for the operator.

For fixed workstations

FS-QXQ lifters are ideal for fixed workstations and can be used with pillar jib cranes, wall-mounted jib cranes or overhead cranes. Very convenient and efficient.

Efficiency and quality

With a focus on efficiency and quality, the lifter is designed to simplify the glass deep processing workflow, raising productivity and reducing operating complexity. It delivers reliable performance and a long service life.
