FS-DFX

Safe working load600–1,000 kg
PowerDC 48 V battery
Suction cups6–12 × Φ300
Tilt / rotationElectric 0–90° tilt, 0–360° rotation
ControlWireless remote
Frame3 sections, (625+1400+625)×1000×480 mm

FS-DFX electric tilt and rotate glass vacuum lifter

FS-DFX is a series of glass vacuum lifters with electric tilting and rotation. Safe working load is 600 to 1,000 kg, powered by a DC 48 V battery.

The frame is assembled from three sections, so the lifter suits glass of different sizes and outdoor curtain wall installation. A high-precision gear mechanism tilts the glass 0–90° and rotates it 360° electrically, smoothly and reliably. The lifter is operated by wireless remote control, and the high-capacity battery gives a long working time per charge.

FS-DFX electric tilt and rotate glass vacuum lifter with 12 pads

Specifications

Model	Safe working load	Size (mm)	Pad diameter (mm)	Number of pads	Power system	Control	Function
FS-DFX600-6S	600 kg	(625+1400+625)×1000×480	Φ300	6 pcs	48 V	Wireless remote	0–90° electric tilt + 0–360° electric rotation
FS-DFX800-8S	800 kg	(625+1400+625)×1000×480	Φ300	8 pcs	48 V	Wireless remote	0–90° electric tilt + 0–360° electric rotation
FS-DFX1000-12S	1,000 kg	(625+1400+625)×1000×480	Φ300	12 pcs	48 V	Wireless remote	0–90° electric tilt + 0–360° electric rotation

All three models share the (625+1400+625)×1000×480 mm frame, Φ300 pads, 48 V power, control and functions; they differ in pad count and safe working load.

Main components

Vacuum pump

Low energy consumption / High vacuum, strong suction / Well-known brand, can run 24 hours continuously with more stable performance

Vacuum suction cup

Pad rubber diameter 300 mm, nitrile rubber / Three-ring multi-cavity seal, holds pressure well and is safer

Equipment frame

Custom made by the factory / National standard structural steel profiles / Welded, machined, shaped and baked-paint finished, durable

Other spare parts

Power switches from internationally known brands, high-quality brushless motors, etc. / UL and other international certifications / Low failure rate, durable

Part details

Numbers on the drawing match the part names below (shown: FS-DFX800-8S).

Lifting ring
Battery control box
Vacuum system
Vacuum suction cup
Main frame
Vacuum hose
Rotation brushless motor
Rotation speed reducer
Rotation gear set
Tilt gear set
Tilt speed reducer
Tilt brushless motor
Remote control receiver
Power switch
Electric drive system
Vacuum indicator lamp
Alarm lamp
Power indicator
Vacuum pressure sensor

On site

**Lifting a large glass panel flat in the workshop**

**Glass turned upright under the crane**

**Steel plate held upright, lifter rotated to portrait**

**Picking glass from a crate, two operators guiding**

**4-pad version with guide handles tilting a steel plate**

Applications

**Powered tilting and rotating of insulating glass**FS-DFX800-8S (800KG)

**Powered tilting and rotating of carbon-steel sheet**FS-DFXJ600-6S (600KG)

**Powered tilting and rotating of steel sheet**FS-DFXJ600-6S (600KG)

Advantages

Electric 0–90° tilt and 360° rotation

A key feature of the FS-DFX series is its high-precision gear mechanism, which tilts the glass 0–90° and rotates it 360° electrically, stable and reliable in operation. This improves efficiency and keeps the whole lifting process safe.

Wireless remote, long battery life

Wireless remote control makes the lifter more efficient and easier to use: precise handling and adjustment, less manual effort and lower risk of accidents. The high-capacity battery and long battery life keep the lifter working without interruption, a reliable and efficient tool for building installation projects.

Workshop or job site

Whether handling glass panels for processing indoors or installing outdoor curtain walls, this glass vacuum lifter is a suitable solution for professionals in the trade.
