| Specifications | FSDC0530-B | FSDC1030-B | FSDC2030-B |
|---|---|---|---|
| Lifting capacity (kg) | 500 (min. reach) 250 (max. reach) |
1000 (min. reach) 500 (max. reach) |
2000 (min. reach) 1000 (max. reach) |
| Max. lifting height (mm) | 3000 | 3000 | 3000 |
| Battery capacity (V/Ah) | 24/165 | 24/180 | 24/210 |
| Charger (V/A) | 24/20 | 24/25 | 24/30 |
| Hydraulic lift pump power (kW) | 2.5 | 2.5 | 2.5 |
| Drive motor power (kW) | AC1.5 | AC1.5 | AC1.5 |
| Boom slewing angle | ±90° | ±90° | ±90° |
| Outrigger length (mm) | 950 | 950 | 950 |
| Inner width between outriggers (mm) | 680 | 680 | 680 |
| Total width of both outriggers (mm) | 990 | 990 | 990 |
| Ground clearance (mm) | 200 | 200 | 200 |
| Distance from hook to nearest outrigger (mm) | 420 | 400 | 350 |
| Truck weight (kg) | 890 | 910 | 1050 |
| Overall dimensions (L×W×H) mm | 2900×990×1800 | 3100×990×1600 | 3300×990×1800 |
| Turning radius (mm) | 3100 | 3300 | 3500 |
| Min. aisle width (mm) | 1100 | 1100 | 1100 |
| Drive wheel (mm) | 1 × Φ250 × 80 | 1 × Φ250 × 80 | 1 × Φ250 × 80 |
| Auxiliary wheels (mm) | 2 × Φ150 × 50 | 2 × Φ150 × 50 | 2 × Φ150 × 50 |
| Front wheels (mm) | 2 × Φ150 × 75 | 2 × Φ150 × 75 | 2 × Φ150 × 75 |
| Gradeability (%) | 4/6 | 4/6 | 4/6 |
| Travel speed (laden/unladen) km/h | 4/6 | 4/6 | 4/6 |
| Lifting speed (laden/unladen) mm/s | 45/50 | 45/50 | 45/50 |
| Lowering speed (laden/unladen) mm/s | 45/40 | 45/40 | 45/40 |
| Brake | Electromagnetic braking | ||
