ENDO Retractor ERM Series

ENDO Retractor ERM Series is part of the ENDO Retractor range. ENDO retractors pull the tool back to its original position after use; the tension increases as the rope is drawn out.

  • The retractor is a spring balancer whose tension of a spring is changed with an extension of a wire rope.
  • Maximum wire rope travel is relative to the setting of the spring tension. (see catalog).
  • Fall-arrest device is equipped on ERM-4S, 6S, and 8S.
  • The ratchet stopper device can be turned on or off according to your requirement.
  • The top hook can be detached without disassembling the retractor body.
  • ERM-2 is a successor model to ER-3A/3B.
  • ERM-4 is a successor model to ER-5A/5B.

Product Video

Specifications

※Wire length varies depending on tension setting and suspension load (see catalog)

Model Fall prevention device Capacity (kg)Wire rope travel (m)※Mass (kg)
ERM-2-1.0～2.03.51.8
ERM-4-2.0～4.03.52.0
ERM-6-4.0～6.02.52.0
ERM-8-6.0～8.02.52.0
ERM-4SYes2.0～4.03.52.0
ERM-6SYes4.0～6.02.52.0
ERM-8SYes6.0～8.02.52.0
