ENDO EW Series Spring Balancer

ENDO EW Series Spring Balancer is part of the ENDO Standard Spring Balancer range. ENDO standard spring balancers from 0.3 kg to 200 kg: EK, ERP, EW, EWS, EWF, ETP, ELF and EWA series.

Its capacity is 1kg-5kg.
This balancer is a standard type that can be used for a broad range of applications.
For suspending electrical devices, jigs, tools, and materials for processed goods.
Centering operations. Balancing device for various kinds of equipment.

Specifications

Model	Capacity (kg)	Stroke (m)	Wire rope diameter (mm)	Mass (kg)	How to adjust spring tension	Fall arrest device	Drum lock device
EW-3	1.0～3.0	1.3	3.0	1.4	Ratchet	－	－
EW-5	2.5～5.0	1.3	3.0	1.5	Ratchet	－	－

Optional Accessories

Plain trolley

When attached to a beam, this trolley enables smooth horizontal movement by hand.

Contact FullSharp for a quotation
