DV-6s carry on

COMEUP DV-6s carry on – 2.7 Tonnes Portable Winch. DV Premium series: COMEUP premium automotive winches for recovery and self-recovery.

Heavy duty series wound motor delivers superior torque output and faster line speed.
Lightweight and compact design is easy for front of vehicle.
2” rear receiver and quick connector wiring kits for rear of vehicle.
Submersible sealed contactor handles high amps and allows higher duty cycle
12 strand construction synthetic rope, coated to improve abrasion resistance and to protect from the ingress of dirt and grit.
The U.S Germany, U.K. France, etc patented automatic, full load cone brake structure outside the drum holds the full load without slippage..
Meets international standards of CE Machinery Directive 2006/42/EC, and CE Electromagnetic Compatibility Directive 2014/30/EU

Technical Specifications

Part number	PN 854765 (12V)
Rated line pull	2,722 kg / 6,000 lb single line
Motor	2,390 w / 3.2 hp 12V series wound
Gear ratio	3-stage planetary 216:1
Clutch (freespooling)	Rotating ring gear
Brake (outside the drum)	Automatic, full load CBS (Cone Brake Structure)
Winch construction	Aluminum die cast housings with steel drum
Drum size	63.5 mm x 125.5L mm (2.5” x 4.9”L)
Control	Waterproof remote w/ 5 m (17') cord
Rope type	Synthetic rope
Rope size	8 mm x 24.4 m (5/16” x 80’)
Mounting bolt pattern	152.4 mm x 114 mm (6” x 4.5”) Standard Compliance: - CE Machinery Directive 2006/42/EC - CE EMC Directive 2014/30/EU

Line Speed and Amp. Draw (1st layer of wire rope on the drum):

Line Pull and Rope Capacity:

Warning

The winch is not intended to be used in any manner for the movement or lifting of personnel.
The rated line pull shown is based on the first layer of rope on the drum.
The rope winding on the drum shall remain 10 wraps from the drum.

Warranty

Limited lifetime warranty for mechanical components and one(1) year warranty for electrical components from date of purchase. Wire/Synthetic ropes are not included under warranty.

Standard Accessories:

Document	Date	Format	Download
DV-6s carry on Operation Manual	2022-05-02	PDF, 0.61 MB	Download
