Description

POROUS PLASTIC EXHAUST MUFFLERS

Vacuum exhaust mufflers in high density polyethylene – 10-32 to 1″ NPT

Product Overview

Porous plastic muffler range

ANVER Porous Plastic Exhaust Mufflers are available in several styles to meet your noise reduction requirements. They all feature standard NPT threads and reduce exhaust noise to within OSHA standards. ANVER Exhaust Mufflers can be used on vacuum pumps, small compressors, pneumatic valves, air motors, rotary/impact air tools, or other similar equipment.

Features

Reduces noise levels to within OSHA standards
One-piece design helps prevent “Blow-out”
Inert material is non-corrosive
Internal ribs provide structural integrity

Specifications

Porous Plastic Mufflers
Parameter	Value
Materials	High Density Polyethylene (HDPE)
Maximum temperature	180°F (82°C)
Maximum operating pressure	150 psig
Decibel rating	60–80 dB(A)

(Actual noise reduction depends on application, port size, and working pressure.)

A thread · B diameter · C length

Muffler Specifications

Porous plastic exhaust mufflers
ANVER part number	Exact replacement for P-Style muffler no.	A thread (NPT)	B diameter [in. (mm)]	C length [in. (mm)]	Filter size [microns]	Weight [oz. (g)]
M-1032/30	N/A	10-32	0.30 (7.6)	0.94 (24)	30	0.01 (0.28)
M-18/30	N125FF	1/8″	0.50 (12.7)	1.15 (29)	30	0.03 (0.85)
M-18/100	N125	1/8″	0.50 (12.7)	1.15 (29)	100	0.03 (0.85)
M-14/30	N250FF	1/4″	0.66 (16.8)	1.40 (35.6)	30	0.10 (2.84)
M-14/100	N250	1/4″	0.66 (16.8)	1.40 (35.6)	100	0.10 (2.84)
M-38/30	N375FF	3/8″	0.95 (24.1)	2.70 (68.6)	30	0.20 (5.67)
M-38/100TOP SELLER!	N375	3/8″	0.95 (24.1)	2.70 (68.6)	100	0.20 (5.67)
M-12/30	N500FF	1/2″	0.95 (24.1)	2.70 (68.6)	30	0.30 (8.50)
M-12/100	N500	1/2″	0.95 (24.1)	2.70 (68.6)	100	0.30 (8.50)
M-34/30	N750FF	3/4″	1.53 (38.8)	5.80 (147)	30	0.60 (17.01)
M-34/100	N750	3/4″	1.51 (38.3)	5.82 (148)	100	0.60 (17.01)
M-10/30	N1000FF	1″	1.89 (48.0)	6.61 (168)	30	1.20 (34.02)
M-10/100	N1000	1″	1.89 (48.0)	6.61 (168)	100	1.20 (34.02)
