Description
VACUUM SLIDE VALVES
Sleeve valves for vacuum or pressure applications
Product Overview
Slide valve range
ANVER Slide Valves are manually controlled, 3-way functioning valves that vent the downstream vacuum or pressure when the valve is turned to the OFF position. This provides a simple, yet effective way of controlling the vacuum or pressure that is generated. These slide valves are field proven to offer long-lasting, maintenance-free operation.
Features
Construction
- Anodized aluminum sleeve for longevity
- Chrome-plated brass body for corrosion resistance
Operation
- Fingertip ON/OFF control
- Smooth, but not loose, transition
Applications
- Ideal for use where intermittent vacuum or pressure control by the operator is required
- Works with vacuum lifting systems and handling equipment
Specifications
| Vacuum slide valves | |
|---|---|
| Parameter | Value |
| Max. pressure | 150 psi (10 bar) |
| Max. vacuum | 29 in. Hg (980 mbar) |
| Temperature | 0° to 160°F (-18°C to +70°C) |
Standard sliding sleeve valve – A · B dimensions
Locking sliding sleeve valve – A · B dimensions
Slide Valve Specifications
| Part number | Description | Thread (female) | A [in. (mm)] | B [in. (mm)] | Item weight [oz. (grams)] |
|---|---|---|---|---|---|
 SV-18 |
Standard sliding sleeve valve | 1/8″ NPTF | 1.89 (48) | 0.98 (25) | 1.799 (51) |
 SV-14 |
Standard sliding sleeve valve | 1/4″ NPTF | 2.28 (58) | 1.18 (30) | 2.998 (85) |
 SV-14L |
Locking sliding sleeve valve | 1/4″ NPTF | 1.82 (46) | 1.22 (31) | 3.175 (90) |
 SV-38 |
Standard sliding sleeve valve | 3/8″ NPTF | 2.75 (70) | 1.38 (35) | 5.609 (159) |
 SV-12 |
Standard sliding sleeve valve | 1/2″ NPTF | 3.15 (80) | 1.57 (40) | 8.042 (228) |
 SV-12L |
Locking sliding sleeve valve | 1/2″ NPTF | 2.45 (62) | 1.61 (41) | 7.372 (209) |
 SV-12BL |
Standard sliding sleeve valve | 1/2″ NPTF | 3.15 (80) | 1.57 (40) | 8.995 (255) |
Other sizes of locking slide valves are available. Consult factory for more information.
