VACUUM RESERVOIR
For below the hook vacuum lifters and vacuum automation systems
Product Overview
28400138 vacuum reservoir
ANVER’s Vacuum Reservoir can be used inline or as a single-ported auxiliary tank for faster attach. When used inline on non- to semi-porous loads, it adds safety in case of a power failure by increasing the vacuum in a system allowing more time to safely lower the load. As an auxiliary tank it greatly increases the speed of attachment if opened after a suction cup has seated on a load and the attach mode has been activated. This is achieved using special valve circuits. ANVER’s series of large vacuum generators use this system and come with built in reservoirs.
Features
Construction
- Made from sturdy 14 GA steel tubing and 11 GA end caps
- Welded to ANSI/AWS D14.1 specifications
- Volume of 100 cubic inches (1639 cc)
- Durable safety-yellow powder-coated finish
Integration
- 3/8-NPT port provides easy integration into a vacuum system
- 3/8″ x 1/2″ mounting bracket, longitudinally welded to the tank side, provides a means to rigid mount the tank within a system configuration
- May also be used as a low pressure compression tank
Maximum pressure: 110 psi – NOT ASME certified
Volume: 100 cubic inches (1639 cc) · Weight: 4.15 lb. (1.88 kg)
Specifications
| ANVER item number | Volume [cubic in. (cc)] | Volume [gal. (L)] | Height [in. (mm)] | Diameter [in. (mm)] | Weight [lb (kg)] | 3/8″ fittings for clamps and hose | 3D models |
|---|---|---|---|---|---|---|---|
| 28400138 | 100 (1639) | 0.45 (1.7) | 9.24 (235) | 4.00 (102) | 4.15 (1.88) |  |
SolidWorks · TraceParts |
NOTE: The finish on the fittings for clamps and hoses is being changed to brass. Until all the stock has been depleted, nickel-plated fittings may be shipped.
