VACUUM MANIFOLD BLOCKS
Vacuum system accessories – anodized aluminum manifolds with mounting plates, 1/8″ to 1/2″ NPT
Product Overview
Manifold blocks with mounting plates
Features
- Compact and lightweight
- Made from anodized aluminum
- Through holes provided for mounting
- Four standard sizes available
- 1/4″ NPT gauge port is standard with MBC Series
- Adapter plate for mounting on flat surfaces available for all manifolds
- Make precise, professional installations easy
Application
ANVER quality manifolds have been designed to provide efficient distribution connections for vacuum or medium pressure systems.
Specifications
| Vacuum manifold blocks | |
|---|---|
| Parameter | Value |
| Maximum pressure | 1000 psi |
| Vacuum | 30 in. Hg |
| Temperature | -65 to 250°F |
A · B · C · D · E · F dimensions
MBC Series with center port
Dimensional Specifications
| Part number | Type | Pipe thread | A [in. (mm)] | B [in. (mm)] | C [in. (mm)] | D [in. (mm)] | E [in. (mm)] | F [in. (mm)] | Item weight [oz. (grams)] | Adapter plate number | 3D models |
|---|---|---|---|---|---|---|---|---|---|---|---|
 MB-18F |
Manifold only | 1/8″ NPT | 0.157 (4) | 0.18 (4.5) | 0.99 (25) | 0.66 (17) | 0.59 (15) | 0.49 (12.5) | 0.5997 (17) | MBAP-1 | SolidWorks · TraceParts |
 MB-14F |
Manifold only | 1/4″ NPT | 0.26 (7) | 0.22 (5.5) | 1.57 (40) | 1.00 (26) | 0.78 (20) | 0.78 (20) | 2.1517 (61) | MBAP-2 | SolidWorks · TraceParts |
 MBC-14F |
With center port | 1/4″ NPT | 0.26 (7) | 0.22 (5.5) | 1.57 (40) | 1.00 (26) | 0.78 (20) | 0.78 (20) | 2.0988 (59.5) | MBAP-2 | SolidWorks · TraceParts |
 MB-38F |
Manifold only | 3/8″ NPT | 0.31 (8) | 0.22 (5.5) | 1.97 (50) | 1.33 (34) | 0.98 (25) | 0.98 (25) | 4.3387 (123) | MBAP-3 | SolidWorks · TraceParts |
| MBC-38F |
With center port | 1/4″ NPT | 0.31 (8) | 0.22 (5.5) | 1.97 (50) | 1.33 (34) | 0.98 (25) | 0.98 (25) | 4.3916 (124.5) | MBAP-3 | SolidWorks · TraceParts |
 MB-12F |
Manifold only | 1/2″ NPT | 0.31 (8) | 0.22 (5.5) | 1.97 (50) | 1.33 (34) | 1.18 (30) | 0.98 (25) | 5.2382 (148.5) | MBAP-3 | TraceParts |
| MBC-12F |
With center port | 1/4″ NPT | 0.31 (8) | 0.22 (5.5) | 1.97 (50) | 1.33 (34) | 1.18 (30) | 0.98 (25) | 5.1500 (146) | MBAP-3 | TraceParts |
Installation Examples
