VB VACUUM HOIST LIFTERS
Integrated hoist-powered vacuum lifting for bags, cartons and porous loads – up to 700 lbs [317 kg]
Product Overview
Standard control head – VBS-DC-Q
The ANVER VB vacuum lifting system is a complete integrated unit built for fast, safe, one-operator handling of bags, cartons and other porous materials.
A high-flow direct-drive vacuum pump supplies the holding force, while a robust electric chain hoist performs the lift. The result is a firm, non-slip grip that is insensitive to load weight.
The system can be supplied with an air hoist, electric hoist or air balancer to suit the application.
Remote vacuum pump – can sit up to 150 ft [46 m] from the lifting head.
Fingertip controls on the handle, with vacuum gauge and quick-release fitted as standard.
Extruded aluminium or steel frame, with interchangeable pads matched to each load type.
Three Control Head Ranges
Standard
- Base VB control head.
- Straight or extended / pivoting handle.
- Standard load capacity.
Heavy-Duty
- Capacity to 700 lbs [317 kg].
- Extruded aluminium or steel frame.
- For heavy-load applications.
Pneumatic Tilt
- Model 74000118 – 200 lbs.
- Model VBT25M2-61-1220NBR – 250 lbs.
- 90° powered tilt.
Standard Control Head – VBS-DC-Q / VBS-DC-B
VBS-DC dimensional drawing
The VB Vacuum-Hoist Lifter draws vacuum from a remotely mounted pump up to 150 ft [46 m] away, and takes a range of quick-change pads for different loads. A vacuum gauge and quick-release are fitted as standard, with all controls at the operator’s fingertips on the handle.
Frames are available in extruded aluminium or steel, with custom pads matched to the specific load. The grip is firm and non-slip, and the unit can be paired with an air hoist, electric hoist or air balancer.
The illustration shows a control head fitted with a BH90-SSP-C5 bag-lifting pad – supplied separately.
Pad attachments available
| Pad type | Suits |
|---|---|
| Rectangular pad attachments | Cartons, boxes, sheet and panel loads with a flat face. |
| Bag lifting pad attachments | Sacks and bags – the pad conforms to a soft, uneven surface. |
| Standard round pad attachments | Drums, pails and round or irregular loads. |
Standard control head – part numbers & sizes
| Quick Release (VB-Q) | Bolt-On (VB-B) | A – horizontal length in (mm) |
|---|---|---|
| VBS-DC-Q | VBS-DC-B | 14.75 (375) |
| VBX-24DC-Q | VBX-24DC-B | 24 (610) |
| VBX-30DC-Q | VBX-30DC-B | 30 (762) |
| VBX-36DC-Q | VBX-36DC-B | 36 (914) |
Extended / pivoting control head
VBX-DC dimensional drawing
| Quick Release (VB-Q) | Bolt-On (VB-B) | A – horizontal in (mm) | B – pivoting in (mm) |
|---|---|---|---|
| A = 12 in [305 mm] | |||
| VBX-1224DC-Q | VBX-1224DC-B | 12 (305) | 24 (610) |
| VBX-1230DC-Q | VBX-1230DC-B | 12 (305) | 30 (762) |
| VBX-1236DC-Q | VBX-1236DC-B | 12 (305) | 36 (914) |
| A = 20 in [508 mm] | |||
| VBX-2015DC-Q | VBX-2015DC-B | 20 (508) | 15 (381) |
| VBX-2020DC-Q | VBX-2020DC-B | 20 (508) | 20 (508) |
| VBX-2024DC-Q | VBX-2024DC-B | 20 (508) | 24 (610) |
| VBX-2030DC-Q | VBX-2030DC-B | 20 (508) | 30 (762) |
| VBX-2036DC-Q | VBX-2036DC-B | 20 (508) | 36 (914) |
| A = 24 in [610 mm] | |||
| VBX-2415DC-Q | VBX-2415DC-B | 24 (610) | 15 (381) |
| VBX-2420DC-Q | VBX-2420DC-B | 24 (610) | 20 (508) |
| VBX-2424DC-Q | VBX-2424DC-B | 24 (610) | 24 (610) |
| VBX-2430DC-Q | VBX-2430DC-B | 24 (610) | 30 (762) |
| VBX-2436DC-Q | VBX-2436DC-B | 24 (610) | 36 (914) |
| A = 30 in [762 mm] | |||
| VBX-3015DC-Q | VBX-3015DC-B | 30 (762) | 15 (381) |
| VBX-3020DC-Q | VBX-3020DC-B | 30 (762) | 20 (508) |
| VBX-3024DC-Q | VBX-3024DC-B | 30 (762) | 24 (610) |
| VBX-3030DC-Q | VBX-3030DC-B | 30 (762) | 30 (762) |
| VBX-3036DC-Q | VBX-3036DC-B | 30 (762) | 36 (914) |
| A = 36 in [914 mm] | |||
| VBX-3615DC-Q | VBX-3615DC-B | 36 (914) | 15 (381) |
| VBX-3620DC-Q | VBX-3620DC-B | 36 (914) | 20 (508) |
| VBX-3624DC-Q | VBX-3624DC-B | 36 (914) | 24 (610) |
| VBX-3630DC-Q | VBX-3630DC-B | 36 (914) | 30 (762) |
| VBX-3636DC-Q | VBX-3636DC-B | 36 (914) | 36 (914) |
Part number convention: VBX-AABBDC-Q/B, where AA = horizontal length (in), BB = pivoting length (in), Q = quick release and B = bolt-on. Example: VBX-2424DC-Q = 24″ horizontal + 24″ pivoting, quick release.
Heavy-Duty Control Head – VBS-DC-B-HD
VBS-DC-B-HD
The heavy-duty head carries the same remote-pump architecture and fingertip controls, rated for loads up to 700 lbs [317 kg].
Supplied with an extruded aluminium or steel frame and custom pads matched to the load. The illustration shows the head fitted with an FPA120290G33-VB-HD pad – specified separately for each application.
Technical drawing – main vacuum hose and hoist pendant omitted for clarity
| Specification | VBS-DC-B-HD |
|---|---|
| Maximum mechanism capacity [lbs (kg)] * | 700 (317) |
| Unit weight, excluding pad [lbs (kg)] | 30 (14) |
| A – maximum headroom [in (mm)] | 7.5 (190) |
| B – unit width [in (mm)] | 14.75 (375) |
| C – handle length [in (mm)] | 14.69 (373) |
| D – handle height [in (mm)] | 5.61 (142) |
| E – mounting centre distance [in (mm)] | 9 (229) |
* Actual maximum lifting capacity depends on the pad attachment and vacuum pump used. Contact FULL-SHARP for help configuring the system.
Pneumatic Tilt Control Heads
A hoist-powered vacuum lifter with high air flow and a compressed-air tilt mechanism, for handling construction materials, composites and textured surfaces. Designed for 100% duty cycle, with pads sized to the application – including foam pads up to 20″ × 25″. Fully integrated controls cover variable-speed hoist, vacuum attach and release, and the tilt function. Tilt requires 75 psi compressed air.
Model 74000118 – 200 lbs
74000118 – 90° pneumatic tilt
Drawing – hoses and pendant omitted
| Specification | 74000118 |
|---|---|
| Maximum mechanism capacity [lbs (kg)] * | T.B.D. – depends on configuration |
| Unit weight [lbs (kg)] | 70 (32) |
| Compressed air required [psi] | 75 |
| Tilt speed | Variable (100% duty cycle) |
| A – vertical headroom [in (mm)] | 32.62 (829) |
| B – horizontal headroom [in (mm)] | 28.14 (715) |
| C – pad dimension [in (mm)] | 12.1 × 20.5 (307 × 521) |
| D – handle length [in (mm)] | 18.16 (461) |
| E – vertical handle height [in (mm)] | 30.73 (781) |
| F – horizontal handle height [in (mm)] | 26.25 (667) |
| Pad supplied | VP1220A |
Model VBT25M2-61-1220NBR – 250 lbs
VBT25M2-61-1220NBR dimensional drawing
| Specification | VBT25M2-61-1220NBR |
|---|---|
| Maximum mechanism capacity [lbs (kg)] * | 250 (113) |
| Unit weight [lbs (kg)] | 138 (63) |
| Compressed air required [psi] | 75 |
| Tilt speed | Variable (100% duty cycle) |
| A – vertical headroom [in (mm)] | 37.56 (954) |
| B – horizontal headroom [in (mm)] | 29.75 (756) |
| C – pad dimension [in (mm)] | 12.1 × 20.5 (307 × 521) |
| D – beam length [in (mm)] | 18.16 (461) |
| E – maximum pad spacing [in (mm)] | 60 (1,524) |
| E – minimum pad spacing [in (mm)] | 25 (635) |
| F – fixed handle length [in (mm)] | 13 (330) |
| G – pivoting handle length [in (mm)] | 19.69 (500) |
* Maximum lifting capacity depends on the vacuum pump used. Contact FULL-SHARP to confirm the configuration for your application.
