E-Float Hoist™
Knight Global E-Float Hoist™
Series: KSBA150 / KSBC150 / KSBC300
The Knight E-Float Hoist™ is a high-performance servo hoist built for flexible, efficient material handling. It delivers Knight’s exclusive Float Mode without an inline load cell.
The extremely low-profile design reduces stack-up height, which suits headroom-limited installations. Maximum capacity is 300 lbs [136 kg].
A sealed gearbox gives long service life and quiet running. The modular construction allows fast access during inspection or maintenance. An E-Float Hoist+ version is available with custom tooling integration, custom programming and full I/O capability.
*Note: Models ending in -P are the E-Float Hoist+ version with full I/O. Contact FULLSHARP for help choosing the right configuration for your project.
General Information – The E-Float Hoist Includes
Mechanical
- Low profile – reduces stack-up height.
- Available with wire rope or link chain:
- Holding brake.
- Chain / rope travel – 80 in. standard.
- Sealed gearbox.
- Meets and exceeds industry standards.
- H5 duty rating – continuous duty cycle.
- Modular design for fast maintenance, including rope and chain replacement.
- CE and UL compliant.
- Speed – up to 241 fpm [73.5 mpm].
- Maximum capacity – up to 300 lbs [136 kg].
Software
- Automatic balance mode to 300 lbs.
- STO – Safe Torque Off.
- Advanced user interface (UI).
- Ethernet connectivity.
- Programming and diagnostic port.
- Speed reduction zones.
- Impact limiting.
- Active damping.
- Knight’s proprietary Float Mode.
- Programmable overload capability.
- Advanced diagnostics and fault monitoring.
Electrical
- Load sensing.
- 240 V operation.
- Status LEDs: illuminated green and blue buttons.
- Fault LED: illuminated Run / Stop button.
- Standard control handles:
- Rocker type.
- Two-speed type.
- Standard power cable: straight cable (KCA1041-10).
Optional Features **
- Wireless control handle.
- Fixture-mounted handle.
- Inline handle.
- Balance chain hook (BPA2113).
- Custom programming to suit the application.**
- 24 VDC, 2 A supply for custom tooling:**
- Grippers, vacuum cups, switches, sensor lights and more.
- I/O capability:**
- (4) analogue inputs / (4) analogue outputs.
- (24) configurable I/O.
- (8) dedicated inputs / outputs.
- Expansion I/O over Ethernet, unlimited.
** Available only on the E-FLOAT HOIST+ version
*Load trolley NOT included – see the accessories section below
E-Float Hoist Specifications
| Model Code * | Max Capacity lbs [kg] | Max Speed fpm [mpm] | |
|---|---|---|---|
| WIRE ROPE | KSBA150-80-S-2401-002 | 150 lbs [68 kg] | 241 fpm [73.5 mpm] |
| KSBA150-80-P-2401-002 | 150 lbs [68 kg] | 241 fpm [73.5 mpm] | |
| CHAIN | KSBC150-80-S-2401-002 | 150 lbs [68 kg] | 241 fpm [73.5 mpm] |
| KSBC150-80-P-2401-002 | 150 lbs [68 kg] | 241 fpm [73.5 mpm] | |
| KSBC300-80-S-2401-002 | 300 lbs [136 kg] | 241 fpm [73.5 mpm] | |
| KSBC300-80-P-2401-002 | 300 lbs [136 kg] | 241 fpm [73.5 mpm] |
* Models ending in -P are the E-FLOAT HOIST+ version with full I/O | BA = wire rope | BC = link chain
Controls
KCA1213
Analogue Remote Handle – Rocker Type
- UP / DOWN rocker switch.
- Illuminated Run / Stop button.
- Lightweight 3D-printed housing.
- Ethernet port for parameter setup.
Weight: 2.5 lbs [1.13 kg]
KCA1214
Analogue Remote Handle – Paddle Type
- UP / DOWN thumb paddle.
- Illuminated Run / Stop button.
- Lightweight 3D-printed housing.
- Ethernet port for parameter setup.
Weight: 2.9 lbs [1.3 kg]
KLCA1080
Inline Handle with Trigger
- Load Monitoring Module (LMM).
- 500 lbs load cell.
- M12 Ethernet port.
- Enhanced response for high-throughput work.
Weight: 15 lbs [6.81 kg]
General Accessories
BPA2113
Pneumatic Balance Chain Hook
- Crosby® self-closing gate hook.
- Quick, secure connection.
- 360° swivel.
2.4 lbs [1.08 kg]
BPA2410
Safety Chain Shackle
- 360° swivel.
- Steel construction.
- Secure cable connection.
2.7 lbs [1.23 kg]
BPA2020
Hook with Bail and Latch
- Lif-Lok® latch.
- Max load 2,000 lbs [907 kg].
- Keeps the load in line with the chain.
0.8 lbs [0.36 kg]
KSAA1003
Precision Chain Wear Gauge
- Steel construction.
- Measures 4 mm and 5 mm zinc-plated chain.
0.87 lbs [0.39 kg]
KSAA1011
Servo Hoist Rail Brake
- Parking brake or drag brake.
- Replaceable brake pads.
- Mounts fore or aft of the hoist.
6.0 lbs [2.72 kg]
Load Trolley
General Features
- High-impact nylon wheels with a glass core.
- Side guide rollers with integrated bearings.
- Double-shielded wheel bearings – no lubrication required.
- Continuous operating temperature: -29°C to 120°C.
- Compatible with Knight aluminium rail systems RAD4110 / RAD6110 / RAD7510.
Matching Trolley Models
- KSAA1050 – RAD7510 rail | max 2,500 lbs [1,134 kg] | 9.5 lbs [4.31 kg]
- KSAA1059 – RAD6110 rail | max 1,600 lbs [725 kg] | 7.6 lbs [3.45 kg]
- KSAA1048 – RAD4110 rail | max 900 lbs [408 kg] | 4.5 lbs [2.04 kg]
*Note: The load trolley is NOT included in the standard hoist package and must be ordered separately. Contact FULLSHARP to select the correct trolley for your existing rail system.
Cables & Disconnects
Power Cables
- KCA1041 – straight power cable (standard on the E-Float Hoist):
- Connects the handle to the servo hoist.
- 19-pin military-style connector.
- Lengths from 2 ft to 15 ft.
- KCA1040 – coiled power cable:
- Wraps neatly around the servo chain.
- 90° male / female connectors.
- Lengths from 2 ft to 20 ft.
Disconnects
- KCA1018 – 3 KVA panel: 480 VAC to 240 VAC, for a single-hoist run.
- KCA1055 – 5 KVA panel: for double or triple servo hoist runs.
- KCA1001 / KCA1102 – disconnect stands: adjustable height, floor mounted.
- KCA1100 – I-beam column mount: no drilling required, multiple mounting orientations.
